Racingline Audi VW Brake Caliper and Disc Upgrade MQB Platform 380mm (MK7 Golf/GTI/R & 8V/8S A3/S3/TT/TTS/TTRS)
Racingline Audi VW Brake Caliper and Disc Upgrade MQB Platform 380mm (MK7 Golf/GTI/R & 8V/8S A3/S3/TT/TTS/TTRS)
Questions about this part?
Our technical advisors can confirm fitment for your vehicle. Contact us with your vehicle details.
The RacingLine Stage 3 Forged Monoblock Brake Kit moves braking technology to a level above anything seen before in this market.
Our design vision was made possible by our advanced 5-axis CNC manufacturing techniques to give this kit more in common with top-level motorsport components than typical aftermarket parts. The result is a combination of ultimate track performance with lightness, stiffness and beautiful attention to detail.
Each lightweight Forged Monoblock caliper is a one-piece construction that starts out from an ultra-strong forged billet. Rather than two halves bolted together, our design takes a complex 5-axis CNC machining procedure to build, usually reserved only for the highest-specification motorsport kits.
The result is a 6-piston caliper that is both stiffer and lighter than any other, combined with exceptional cooling characteristics and stunning detailing.
Despite the size of these calipers, they weigh in significantly under the mass of the factory ones. The caliper, pads and bracket assembly together weigh 5.3kg (11.7lb) vs 8.6kg (18.9lb) for the factory Golf 7R / S3 equivalent.
The kit offers a choice of 355mm or 380mm fully-floating ‘triple-grove’ two-piece discs giving vastly greater heat capacity, so reducing the effect of fade.
Please Note: 380mm kit: Minimum 19" wheel diameter required.
MONOBLOCK
The 'Forged Monoblock' construction of our 6-piston aluminium thin-profile calipers give extreme stiffness and light weight, and aid in wheel clearance packaging.
DISC QUALITY
Two-piece floating high cast carbon discs - a mixture of high quality steel combined with carbon; giving a far higher friction coefficient compared to normal steel rotors. In either 355mm or 380mm diameter.
PAD CHOICE
Composite Ceramic Fast-Road Pads are included. We use a generic pad size, meaning a wide choice of pad brands & compounds are available if you're planning hard track use.
FULLY-FLOATING
Fully floating mounting between disc and bell allow for thermal expansion and contraction to avoid cracking. The anti-rattle mounts keep it quiet.
VWG-SPECIFIC
As our kit is engineered exclusively for VWG cars, we've developed piston sizes perfectly matched to master cylinders and servos for beautiful progressive pedal response.
FULL INSTALL KIT
Everything you need for installation: discs, callipers, mounting brackets, fast road pads, braided steel lines. Plus the option of Hub Adaptors for extra wheel clearance. Bolt on & drive!
-
VW Golf 7 5G - 2012+
-
VW Golf 7 GTI 5G - 2013+
-
VW Golf 7 R 5G - 2013+
-
VW Golf 7 GTI ClubSport 5G - 2016+
-
VW Passat & Arteon 2.0 TSI B8 3G - 2015+
-
Audi A3 8V - 2012+
-
Audi S3 8V - 2013+
-
Audi TT III 8S - 2014+
-
Audi TT / TTS 2.0 TSI III 8S - 2014+
-
Audi TTRS III 8S - 2016+
-
SEAT Leon III 5F - 2012+
-
SEAT Leon Cupra III 5F - 2014+
-
Skoda Octavia III 5E - 2013+
-
Skoda Octavia vRS III 5E - 2014+
-
Skoda Superb 1.8 / 2.0 TSI B8 3V - 2015+
VWR650000-RED
Manufactured by
Racingline
